Chapter 4: Tekterm
TRX7370 NB & 802.11 SS Radio Statistics Screen
86
Teklogix 7035, 8255 & 8260 Terminals User Manual
4.4.3 TRX7370 NB & 802.11 SS Radio Statistics Screen
The statistics represented in the sample screen above are defined as follows:
• cq communication quality represented as a percentage value, with 100%
indicating excellent communication quality
• ch operating channel
• sc scan state - indicates the current channel search state
• xm total number of transmitted messages
• xr total number of retransmissions
• xi total number of transmitted initialize messages
• xe total number of transmit failures (transmission late for response
window)
• rm total number of received messages
• ra total number of received radio link aborts
• rp total number of received polls
• pt total number of poll timeouts
cq 35 ch 20 sc 3
xm 17 xr 1
xi 4 xe 0
rm 21 ra 3
rp 106 pt 253
Statistics Connection
