Teklogix 7035, 8255 & 8260 Terminals User Manual 173
Chapter 7: Setting Parameters
View Manager
7.8 View Manager
Anchor View
When enabled (set to “Y”), this parameter locks the display at a defined location on
the screen, preventing it from shifting when the cursor is moved. The “X-origin” and
“Y-origin” coordinates specify where the screen origin, the upper-left corner of the
screen, will be fixed.
X-origin And Y-origin
The “X-origin” parameter is used to specify the column to which the upper left
corner of the screen will be anchored. The “Y-origin” parameter is used to specify
the row coordinate to which the screen will be anchored.
Use increment
When “Use increment” is enabled (set to “Y”) and the cursor is moved off the
display, the screen contents shift by the values specified in the “X-increment” and
“Y-increment” parameters.
X-increment
This parameter determines the number of spaces the screen shifts once the cursor
moves out of view. The value assigned here doesn’t take effect until “Use
Increment” is set to “Y”.
Y-increment
This parameter determines the number of spaces the screen shifts once the cursor
moves out of view. The value assigned here doesn’t take effect until “Use
Increment” is set to “Y”.
Anchor View N Y/N
X-origin 1 1-80
Y-origin 1 1-24
Use Increment N Y/N
X-increment 5 1-40
Y-increment 5 1-12
Display Shift Y Y/N
Custom Chars » see text
Font Override Y» see text
Range
View Manager
