Chapter 9: Specifications
8255/8260 Vehicle-Mount Terminal Specifications
230
Teklogix 7035, 8255 & 8260 Terminals User Manual
Approvals
Safety (applies to chargers) UL 1950, CSA C22.2 No950, LVD
EN 60950
EMC FCC Part 15 Class A, EMC Directive Class B
Laser CDRH/IEC Class II
9.3 8255/8260 Vehicle-Mount Terminal Specifications
8255 – Physical Size And Weight
Enclosure: 16 gauge steel – 1.5 mm (0.060") with baked enamel finish
Size: 287 mm (11.3") W x 102 mm (4.0") D x 229 mm (9.0") H
Weight: 3.8 kg (8.4 lbs)
8260 Display – Physical Size And Weight
Enclosure: 16 gauge steel – 1.5 mm (0.060") with baked enamel finish
Size: 287 mm (11.3") W x 64 mm (2.5") D x 229 mm (9.0") H
Weight: 3.4 kg (7.5 lbs)
8260 Keyboard – Physical Size And Weight
Enclosure: 16 gauge steel – 1.5 mm (0.060") with baked enamel finish
Size: 287 mm (11.3") W x 64 mm (2.5") D x 229 mm (9.0") H
Weight: 1.1 kg (2.4 lbs)
8255 VFD Standard Temp. – Environmental
Note: For 8255 VFD low temp. and freezer terminal operating temperatures
and instructions, refer to “8255/8260 Freezer Terminals” on page 38 and
“8255/8260 Low Temp. Terminals” on page 39.
Operating temperature -10° to 60° C (-14° to 140° F)
Storage Temperature -40° to 70° C (-40° to 158° F)
Relative Humidity 10 to 95% (RH non-condensing)
Shock 30 g peak sawtooth shock pulse, 11 ms
duration on each axis
Random Vibration 1.5 g RMS, 4 Hz to 500 Hz, 60 min duration
on each axis
Rain/Dust IEC 529, IP66 rating
