Chapter 7: Setting Parameters
Network
184
Teklogix 7035, 8255 & 8260 Terminals User Manual
7.12 Network
Note: This menu is not displayed if the “802.IQ” protocol is set to “Y” in the
“Radio” sub-menu or if a narrow band radio is installed in the terminal..
Local IP
This parameter is used to assign a unique terminal IP address so that the terminal
can be identified on the network. The format is ###.###.###.###
Net Mask
A subnet mask is assigned at this parameter. The 7035 uses the subnet mask, it’s
own IP address and the destination IP address to determine if a packet should be sent
on the local network or a remote subnet. If the destination is found to reside on the
local network, the packet is sent directly to its destination. If the destination resides
on a remote subnet, the packet is routed to the appropriate gateway. The accepted
values for “Net Mask” range from 0.0.0.0 to 255.255.255.255.
Note: The terminal “Net Mask” must match the network controller net mask.
Default Gateway
The “Default Gateway” IP address assigned at this parameter creates an identifiable
communication link between the terminal and a remote sub-network – that is, a
network other than the one in which the terminal is currently operating. The
acceptable values for this parameter range from 0.0.0.0 to 255.255.255.255.
Note: Setting the “Default Gateway” to 0.0.0.0 disables this feature.
A communication link will not exist between sub-networks.
Local IP see text
Net Mask see text
Default Gateway see text
Use DHCP N» see text
Use DNS N» see text
Ether Packet Sz 1500 1500 512 1024 1490
Mobile IP N» see text
802.IQ v2 » see text
Network
Range
