Teklogix 7035, 8255 & 8260 Terminals User Manual 135
Chapter 7: Setting Parameters
Barcode
7.6.3 Barcode
All the available bar code symbologies can be selected from this menu. For
each symbology, there are options in a sub-menu. The terminal automatically
discriminates between the selected codes. Some restrictions may apply.
Important: To improve the decode speed and performance, enable (set to “Y”)
only those codes that are required by the application.
7.6.3.1 Code 39
Full Ascii
If this parameter is enabled (set to “Y”), the characters +, %, and / are used as escape
characters. The combination of an escape character and the next character
is converted to an equivalent ASCII character.
Code 39 Y »
Code 128 Y »
EAN 13 Y »
EAN 8 Y »
UPC A Y »
UPC E Y »
Codabar N »
Code 93 N »
Code 11 N »
I 2 of 5 N »
MSI/PLESSY N »
D 2 of 5 N »
IATA 2 of 5 Y »
Barcode
Full Ascii N
Mod 43 Chk N
Mod 10 Chk N
Include Chk N
AIAG Strip N
Err Accept N
Size/Chars »
Code 39
