Teklogix 7035, 8255 & 8260 Terminals User Manual
i
T
ABLE OF
C
ONTENTS
Program License Agreements
.............................xi
Approvals and Safety Summary
..........................xvii
Chapter 1: Introduction
1.1 About This Manual ............................3
1.2 Text Conventions .............................4
1.3 About The Terminals ...........................5
1.3.1 Features ............................5
1.3.2 The 7035 Hand-Held Terminal ................7
1.3.3 7035 Integrated Scanner Patent Numbers ...........11
1.3.4 The 8255 Vehicle-Mount Terminal – LCD or VFD .....11
1.3.5 The 8260 Vehicle-Mount Terminal - LCD Only .......12
Chapter 2: Assembly And Basic Operation
2.1 Preparing Terminals For Operation ....................15
2.1.1 Client-Side Emulation Software................15
2.2 Preparing The 7035 For Operation ....................15
2.2.1 Connecting The 7035 Whip Antenna .............15
2.2.2 The Battery Pack – Removing And Installing.........15
2.2.3 Attaching The 7035 Hand-Strap Or The Pistol Grip .....17
2.3 Installing 8255/8260 Vehicle-Mount Terminals..............18
2.3.1 Mounting The 8255 Vehicle-Mount Terminal ........18
2.3.2 Using The Cradle And Cradle Mounting Plate ........19
2.3.3 Mounting The 8260 Terminal .................21
2.3.4 Connecting The 8255/8260 Antenna .............22
2.3.5 Installing The Cables .....................22
2.3.6 Installing The Extension Power Cable ............23
2.4 Turning The Terminals On And Off....................24
