Chapter 7: Setting Parameters
Applications
146
Teklogix 7035, 8255 & 8260 Terminals User Manual
7.7 Applications
“TESS” and “ANSI” applications require unique names so that several different
sessions of “TESS” and “ANSI” can operate simultaneously. The 7035, 8255 and
8260 terminals can support up to 4 sessions at one time.
Important: These applications will become active only after the changes
made in the Application screen are saved by pressing <F4> –
the SAVE key.
Name And Type
Up to four applications can be entered in this parameter. The “Name #” parameter
must be completed with a name that is meaningful to the operator. The “Type #”
field indicates the type of session you will be running.
• In a “Name #” field, type a name that is meaningful to the operator.
• The available options for the “Type #” field are TESS and ANSI.
Type the appropriate application type in this field using either
uppercase, lowercase or a combination.
• To display the “Settings” menu for your application, position the cursor
on “Settings”, and press <F1> – the NEXT key.
Note: Before you can access the “Settings” menu, you must first complete the
“Name” and “Type” fields.
Name #1 Widget see text
Type #1 ANSI TESS/ANSI
Settings #1 » see text
.
.
.
Name #4
Type #4
Settings #4
Applications
Range
