Chapter 2: Assembly And Basic Operation
Connecting The 8255/8260 Antenna
22
Teklogix 7035, 8255 & 8260 Terminals User Manual
There are three mounting options available. Figure 2.5 on page 21 provides a visual
illustration of the mounting options.
1. The horizontal/vertical mounting cradle (PN 18452) and the keyboard
cradle (PN 18239).
2. The combined mounting option using the horizontal/vertical mounting
cradle (PN 18452-001), the keyboard cradle (PN 18239), and the cradle
support plate (PN 18451).
3. Using the terminal cradle (PN 18198) for the display, the cradle mount-
ing plate (PN 18197) and the keyboard cradle (PN 18239).
2.3.4 Connecting The 8255/8260 Antenna
Warning: Operating the terminal without an antenna may damage the radio.
The antenna consists of the antenna whip and a magnetic mount with cable. To
attach it, follow the guidelines below.
• For narrow band and WAN radios, turn the antenna in a clockwise direction.
• For spread spectrum radios, turn the antenna in a counter-clockwise
direction.
The antenna works best when placed vertically and away from metal objects that
may interfere with the radio signal. The best location for the magnetic mount on a
fork lift truck is on the middle of the roof or cab cover, at least 20 centimeters away
from the operator.
Warning: As a safety precaution, USERS ARE NOT PERMITTED TO
CHANGE THE ANTENNA.
2.3.5 Installing The Cables
Note: Make sure the cables run inside the roll cage.
When installing the cables between the terminal and other devices, consider
the following:
• Ensure the drilling holes will not damage the vehicle or its wiring.
• Protect cable runs from pinching, overheating and physical damage.
• Protect cables by using grommets when cables pass through metal.
• Prevent cables and connectors from moving and loosening by using
plastic straps.
