Chapter 7: Setting Parameters
Ports– Serial 1 And Console 2
176
Teklogix 7035, 8255 & 8260 Terminals User Manual
VTG
When VTG is enabled (set to “Y”), the “Track made good and ground speed”
sentence can be transmitted from the GPS receiver. The data available in a VTG
message includes: Speed (knots), Speed (kilometers per hour) and Direction.
Tx Period
The value assigned to this parameter determines the rate at which the enabled
sentences are transmitted. For example, a value of 10 means that all enabled
sentences will be transmitted at the beginning of each 10 second period.
7.10 Ports– Serial 1 And Console 2
7.10.1 Serial 1 And Console 2 Peripheral Options
The “Serial 1” (COM1) and “Console 2” (COM2) options allow you to enable,
disable and specify the accessories attached to these ports. Possible values include:
Serial 1 – Disable, Enable, Print, Scanner, Output and
IrDA Printer.
Console 2 – Disable, Enable, Print, Scanner, Scan-See, NOMAD
and GPS.
To scroll through the options for each port:
• Press the <RIGHT> or <LEFT> arrow key.
Important: If you choose Disable, the corresponding port parameters will not
take effect.
These ports operate differently depending on the accessories selected.
•“Print” – all TESS print operations are directed to the port. All ANSI media
copy operations to the “primary port” are directed to this port.
•“Scanner” – TESS and ANSI accept scanner input from the port.
•“Scan-See” – TESS and ANSI accepts input from the Scan-See through
Console 2 port. (This option is not available for the Serial 1 port.)
Serial 1 Print
Parameters »
Console 2 Disable
Parameters »
Ports
To Next Page
