Chapter 2: Assembly And Basic Operation
Low Temperature, Freezer and Outdoor Terminals
38
Teklogix 7035, 8255 & 8260 Terminals User Manual
2.12 Low Temperature, Freezer and Outdoor Terminals
Teklogix has developed a range of hand-held and vehicle-mount terminals that
can withstand low temperatures, outdoor use, and/or freezer applications. Each
terminal’s capabilities along with a list of operating guidelines is provided in
this document.
2.12.1 Hand-Held Terminals
7035 Freezer Terminals
Important: A 7035 freezer terminal will cold-start if left in a freezer;
HO
WEVER, you may experience long delays while the internal
heater warms the liquid crystal display to a temperature that can
provide an acceptable refresh rate.
In cases where the 7035 freezer terminal is left to freeze in an
environment below -20˚ C (-4˚ F), and the battery has less than a
30% charge remaining, the terminal may not power up properly.
IN ORDER TO AVOID THESE ISSUES, we recommend that the
7035 freezer terminal be stored and powered up at temperatures
abo
ve 0˚ C (32˚ F).
• For use in temperatures ranging from -30˚ C to 50˚ C (-22˚ F to 122˚ F).
• Water-sealed to IP 54 to withstand rain and condensing environments.
• 7035 terminals must be used with a rubber boot or vinyl protective carrying
case to enhance drop performance below 0˚ C (32˚ F).
2.12.2 Vehicle-Mount Terminals
8255/8260 Standard Temp., Low Temp., and Freezer vehicle-mount terminals are
sealed against dust and high-pressure water jets to the international standard IP66.
8255/8260 Freezer Terminals
Warning: 8255 LCD terminals are not available in a low temperature or
freezer versions.
• 8260 LCD vehicle-mounts: Suitable for use in temperatures ranging from
-30˚ C to 50˚ C (-22˚ F to 122˚ F).
• VFD and EL vehicle-mounts: Suitable for use in temperatures ranging
from -30˚ C to 60˚ C (-22˚ F to 140˚ F).
