7.5 System
The parameters listed under the “System” menu allow you to customize terminal
attributes such as volume, contrast and font size.
7.5.1 Volume And Contrast
Both the terminal beeper volume and the screen contrast can be adjusted using the
<BLUE> key in combination with function keys <F1> to <F4>. However, these
changes are not saved to memory – that is, when the terminal is reset, any volume
and contrast adjustments are lost. For information on manual beeper volume
adjustments, refer to “Beeper Volume – <BLUE> <F3> And <F4>” on page 32.
For details on manual contrast adjustments, refer to “Contrast Adjustment –
<BLUE> <F1> And <F2>” on page 34.
Adjustments made to the terminal beeper and the display using the “Volume” and
“Contrast” parameters are saved to memory so that if the terminal is turned off or
reset, the adjustments are saved.
Volume
The “Volume” parameter is used to adjust the beeper volume of the terminal beeper.
The higher the value entered, the louder the beeper volume of the terminal. The
allowable range is 0 to 15. When a volume adjustment is made using this parameter,
it is saved to memory.
Volume 15 0..15
Contrast 0 -5..5
Key Click Y » see text
One-Shot Mode » see text
Typematic Rpt Y » see text
Caps Lock On N Y/N
Panning » see text
Backlight » see text
Font Size 18x20 see text
Cursor Type Underline see text
Palette Remap » see text
Watchdog timer 0 0..30
Power » see text
Serial Number see text
Range
System
