Teklogix 7035, 8255 & 8260 Terminals User Manual 213
Chapter 8: Terminal Accessories
Mounting Hardware
8.8.1 Mounting Hardware
The 7035 Picker Cradle can be mounted on its own or with one of the following:
• Heavy-duty pedestal mount (PN 30082)
• Pedestal mount with locking joint (PN 18447-001)
• Mounting plate kit (PN 18448-001)
• Scanner mounting plate (PN 18449-001)
• Scanner holder (PN 92892)
8.8.2 Installation
Note: Where applicable, the unit should be mounted inside the roll cage.
Installation requirements vary depending on the type of application used – mobile
(e.g., a fork lift truck) or fixed (e.g., a work table). For a typical installation:
1. Choose a suitable mounting location.
2. If necessary, connect the pass-through cable to an accessory.
3. Connect the power source.
8.8.3 Disassembling The Cradle Before Mounting
Note: If the cradle is attached from behind to a plate or pedestal mount using
the four threaded holes (#8-32) in the rear bracket, it does not need to be
disassembled. Ensure that the screws used are the correct length.
The rear bracket of the cradle also has four ‘through’ holes that allow the cradle
to be attached directly to a surface. Prior to mounting, the plastic cradle must
be removed.
To disassemble the cradle:
• Unscrew the two hex bolts (one per side), and pull away the plastic cradle.
