Chapter 4: Tekterm
802.IQv1 Radio Statistics Screen
4.4.4 802.IQv1 Radio Statistics Screen
The statistics represented in the sample screen above are defined as follows:
• AP mac MAC address of the Teklogix access point/base station with
which this terminal is currently associated.
• bootnum e.g., C33B – the boot number of the network controller. This
number increments each time the controller reboots so that
terminals can detect the reboot when they reinitialize.
• v1 the version of the 802.IQ v1 protocol.
• CQ communication quality represented as a percentage value,
with 100% indicating the best possible communication
quality.
• rm number of unique received messages.
• xm number of unique transmitted messages.
• rb number of received beacons. This number should continu-
ously increment.
AP mac
00:C0:AF:00:43:C0
bootnum: C33B v1
CQ:100
rm 12 xm 7
rb 50 xi 1
ra 7 xa 12
bt 0 xr 1
rt 138 va 30
**Address Info**
Radio Address 1024
Tnum 33, TESS
Tnum 16, ANSI
Tnum 1024, SNMP
MAC ADDR 00:60:1D:04:BD:9D
Serial NO 341220
SysName <the system name>
GroupName <the group name>
802.IQv1 Statistics
To Next Page
