Teklogix 7035, 8255 & 8260 Terminals User Manual 89
Chapter 4: Tekterm
802.IQv2 Radio Statistics Screen
4.4.5 802.IQv2 Radio Statistics Screen
Important: Unlike other statistics screens, pressing <ALT> <F6> does not
immediately display the 802. IQv2 radio statistics screen. Follow
the steps below to display this radio screen.
• Press <ALT> <F6> to display the Telnet statistics screen.
• Press <ORANGE> <N> (Next) to display the 9010t statistics screen.
• Press <N> once again to display the 802.IQv2 statistics screen. If the
<ORANGE> key is locked on, remember to press the it a second time to
deactivate it.
Telnet And 9010t Radio Statistics
Telnet or 9010t statistics are displayed in the top portion of the 802.IQv2 screen.
These statistics are identical to the 802.11 radio statistics and are described in the
section titled “802.11 Radio Statistics Screen” on page 85.
CQ 100
inpkts 31325
outpkts 1223
inbytes 3798828
outbytes 126790
inerrs 12758
outers 0
droppkt 0
------------802.IQ Stats------------
AP/Controller MAC 00:A0:C9:AD:99:70
bootnum: 7737
CQ:100
rm 219 xm 212
rb 783 xi 2
ra 214 xa 226
bt 2 xr 0
rt 710 va 137
------------Address Info------------
Radio Address 1024
Tnum 33, TESS
Tnum 15, ANSI
MAC ADDR 00:60:1D:04:CO:96
Serial NO 346323
SysName <the system name>
GroupName <the group name>
802.IQv2 Statistics
