Teklogix 7035, 8255 & 8260 Terminals User Manual 235
Chapter 9: Specifications
Bar Code Scanning
9.9 Bar Code Scanning
Scanner Types Decoded and non-decoded.
Non-Decoded Codes Supported Code 39, code 128, EAN 13, EAN 8,
EAN 128, UPC-A, UPC-E, Codabar,
Code 93, Code 11, Interleaved 2-of-5,
MSI/PLESSY, Discrete 2-of-5.
Decoded Codes Supported Dependent on external scanner choice.
Code Discrimination Automatic for all selected codes,
Non-Decoded input. Decoded input is exter-
nal scanner dependent.
9.9.1 Internal Scanners (7035 Only)
Note: If you are using a High Performance scanner, choose High Vis for the
“Scanner Type” parameter.
Base Options High performance, long range, advanced
long range and 2-D raster laser scanner.
Scan Triggering If an aiming dot is available on the installed
scanner, the aiming dot will be enabled for
a configurable time period after which
normal scanning begins. Double-clicking
trigger will override aiming delay and initiate
immediate scan.
9.9.2 External Scanners
Supported Types Decoded and Non-Decoded 5V only.
Interface Via peripheral port. Pinout compatible with
all 7030 and 8055 scanners.
9.9.3 Internal Scanner Port (7035 Only)
Refer to Table B.4 "Internal Scanner Connector" in Appendix B: Port Pinouts
And Cable Diagrams for a detailed connector table.
Compatibility Symbol SE1200HP, SE1200LR,
SE1200ALR, SE2223 2-D
