Psion Teklogix 7035 - Decode Zones

Teklogix 7035, 8255 & 8260 Terminals User Manual 239
Chapter 9: Specifications
Decode Zones
9.10.1 Decode Zones
Table 9.3 Decode Zones – Spread Spectrum HP, LR And ALR
Table 9.4 Decode Zones – Narrow Band HP, LR And ALR
Table 9.5 Decode Zones – 2-D Scanner
Bar Code Spread Spectrum
High
Performance
Long Range
Advanced
Long Range
Min Max Min Max Min Max
5 mil 3.0" 4.5"
7.5 mil 3.0" 8.5"
10 mil 2.5" 12.5" 13.0" 17.5"
15 mil 2.5" 18.5" 8.5" 33.5" 20.0" 50.0"
20 mil 2.5" 20.5" 9.5" 38.5" 30.0" 60.0"
40 mil 3.0" 29.5" 9.5" 79.5" 30.0" 98.0"
55 mil 3.5" 35.5" 9.5" 89.5" 27.0" 115.0"
Bar Code Narrow Band
High
Performance
Long Range
Advanced
Long Range
Min Max Min Max Min Max
5 mil 3.0" 5.0"
7.5 mil 2.75" 9.0"
10 mil 2.5" 13.0" 13.0" 18.0"
15 mil 2.5" 19.0" 9.0" 34.0" 20.0" 50.0"
20 mil 2.5" 21.0" 9.0" 39.0" 30.0" 60.0"
40 mil 3.0" 30.0" 10.0" 80.0" 30.0" 98.0"
55 mil 4.0" 36.0" 10.0" 90.0" 27.0" 115.0"
Bar Code
Raster Laser Scanner
Spread Spectrum
2D Bar Codes S2223
Min Max
6.5 mil 2.5" 6.5"
10 mil 2.5" 9.5"
15 mil 2.5" 15.5"
