Teklogix 7035, 8255 & 8260 Terminals User Manual 157
Chapter 7: Setting Parameters
Keyboard
Important: To suspend Smart echo mode if, for example, you are
entering a password, press <ALT> and type ‘.’ (period).
Characters will be replaced with a series of periods until
you press the <ENTER> key.
Local: In this mode, any character entered using the keyboard is displayed before
being sent to the host. Certain keys cause additional action at the terminal,
as shown in Table 7.2 on page 157.
Host: In this mode, the terminal sends all keyboard entries to the host and
displays only data received from the host.
Table 7.2 Function Of Special Keys In Local Echo Mode
DEL Key
This parameter determines which character is sent to the host – DEL (delete) or BS
(backspace). The host interprets how it will respond to the code. The selection made
at this parameter does not affect how the <DEL> key operates at the terminal.
PrintScreen Key
This parameter determines the “hot-key” that will print the screen contents through
the terminal serial port. The default is
16 or <CTRL> P.
Note: The terminal’s serial port must be set for ‘Print’. Refer to “Serial 1 And
Console 2 Peripheral Options” on page 176.
Key Function
ENTER
In Newline mode, this key moves the cursor to the first column
of the next line. In line feed mode, this key moves the cursor to
column one of the current line.
CTRL-G (Bell) The terminal beeps.
CTRL-H (Backspace) The cursor moves back one space.
CTRL-I (Tab) The cursor moves to the next horizontal tab stop.
CTRL-J (Line Feed)
CTRL-L (Form Feed)
The cursor moves down one line in the same column.
CTRL-K (Vertical Tab) The cursor moves down to the next line with a vertical tab set.
DEL
This key deletes the character to the left of the cursor and
moves the cursor to the left by one position.
