Chapter 7: Setting Parameters
Serial 1 And Console 2 Parameter Settings
180
Teklogix 7035, 8255 & 8260 Terminals User Manual
Scan-See – Setting The Terminal Console Port
For proper communication between a Scan-See and a Teklogix terminal,
the console port of the terminal must be properly configured. The parameters
for setting up the console port are located in the “Ports” setup menu, under
“Console 2” in the “Parameters” sub-menu:
The “Console 2” parameters (described on page 177) should be set as follows:
Note: In order for the terminal to interface to Scan-See units with older
firmware (serial numbers lower than 1594120224), set “Parity=space”;
all other parameters are identical to the newer firmware.
For details about the Scan-See sub-menu parameters, refer to the “Scan-See &
Wireless Scan-See Scanner User Manual – PN 80408”.
Nomad – Setting The Terminal Console Port For Nomad
To interface the terminal to the Nomad scanner, “Console 2” must be configured for
NOMAD. For detailed information about configuring the Nomad scanner, refer to the
“LS3070™ Wireless Scanner User Manual” – PN 80416.
Test
This parameter sends a block of ASCII data out the serial port. This function is used
during configuration only and has no effect on the emulation.
Serial 1 Disable
Parameters »
Console 2 Scan-See
Parameters »
Ports
Speed 9600
Data Bits 8
Parity None
Stop Bits 1
Flow Control None
Buffer 512
Scan-See »
Test N
Scan-See
