Chapter 8: Terminal Accessories
Active Transient Filter Power Supply
Note: Water will not harm the Pre Regulator/Transient Suppressor if mounted in
a way that prevents water from pooling in the upper case. The Pre-Reg
should be mounted vertically with the mounting flange face down. The
power module inside the unit is sealed. If mounted properly, the water
drains out of the unit and does not harm the power supply inside the unit.
The diagram below illustrates recommended connection options.
Figure 8.5 Recommended Connections
Note: Teklogix provides another Transient Suppressor (PN 19893-500) that
filters transients but does not provide a power supply.
Filter Only
19893-500
Filter LC
10-100VDC In out
Truck Battery
Dirty power
Power Supply
Model #8742
Active Transient Filter
15-55VDC IN Nom
Filters 168VDC
20msTrans.
18V-36 W out
Terminal
82xx Std Temp, Low Temp
7035 Powered Cradles
Truck Battery
Very Dirty power
Recommended
Connections
13985 Cable
13985 Cable
Terminal
82xx Std, Low Temp, Freezer
7035 Powered Cradle
