Chapter 2: Assembly And Basic Operation
Onscreen Indicators – 7035 Only
30
Teklogix 7035, 8255 & 8260 Terminals User Manual
Table 2.1 7035 Onscreen Indicators
alt
A lowercase alt message indicates the <ALT> key will be active until the
next key is pressed. The next key pressed generates an alternate command as
defined by the application you are using.
ALT
An uppercase ALT message indicates that the <ALT> key function is locked
“on” providing access to alternate commands as defined by the application
you are using until the <ALT> key is unlocked.
blue
A lowercase blue message indicates that the <BLUE> key is active until the
next key is pressed. Any keyboard option colour-coded in blue on the termi-
nal plastic becomes available.
BLUE
An uppercase BLUE message indicates that the <BLUE> key function is
locked “on”. Keyboard options coded in blue typeface are available until the
<BLUE> key is unlocked.
ORANGE
An uppercase ORANGE message indicates that the <ORANGE> key is
locked “on”. Any keyboard option colour-coded in orange on the terminal
plastic becomes available.
orange
A lowercase orange message indicates that the <ORANGE> key will be
active only until the next key is pressed. The alpha characters printed in
orange typeface on the terminal plastic become available.
Battery
Gauge
This horizontal gauge indicates the charge level of the battery.
link
Narrowband
A lowercase link message indicates that a radio link has been established but
the link is currently in power-down mode, a mode that lowers the consump-
tion of battery power. Note that the absence of a link message (either upper-
case or lowercase) indicates that a radio link has not been established.
LINK
Narrowband
Uppercase LINK – This indicates that the radio link is operational. Note that
the absence of a link indicator message (either uppercase or lowercase) indi-
cates that a radio link has not been established.
LINK
802.IQ
Uppercase LINK – The terminal is receiving 802.IQ beacons from an 802.IQ
base station at regular intervals. This indicates that the terminal is within
communicating range of the base station.
Blank – If a LINK onscreen message does not appear, the radio is not within
communicating range of a configured and operating base station.
