4–Managing Fabric Zoning
Managing the Zoning Database
59266-01 B 4-9
Configuring the Zoning Database
Use the Zoning Config dialog box (Figure 4-4) to change the Merge Auto Save,
Default Zone, and Discard Inactive configuration parameters. To view the Zoning
Config dialog box, on the Zoning menu, click Edit Zoning Config. After making
the changes, click OK to put the new values into effect.
Figure 4-4. Zoning Config Dialog Box
Table 4-2. Port/Device Icons
Icon Description
Switch port icon—when not logged in
Switch port icon—when logged in
NL_Port (loop) device icon—when logged in to fabric
NL_Port (loop) device icon—when not logged in to fabric
N_Port device icon—when logged in to fabric
N_Port device icon—when not logged in to fabric
