Qlogic 5800V Series

5–Managing Switches
Configuring the Network
5-34 59266-01 B
1. Select an entry switch in the fabric tree.
2. On the Switch menu, click Network and click Ipsec Properties to view the
IPsec Configuration dialog box (Figure 5-16).
Figure 5-16. IPsec Configuration Dialog Box
Table 5-6 describes the Network IP buttons in the IPsec Configuration dialog box.
NOTE:
The IPsec Configuration dialog box is only available with a secure fabric on
the entry switch.
Table 5-6. IPsec Configuration Dialog Box Buttons
Button Description
Add Opens the Create IP Security Association dialog box in which to add a
new IP security association. Opens the Create IP Security Policy dialog
box in which to add a new IP security policy.
Delete Deletes the selected association or policy.
Edit Opens a dialog box in which to change the selected association or policy.
