Qlogic 5800V Series User Manual

2–Managing Fabrics
Transparent Router
59266-01 B 2-9
Transparent Router
The Transparent Router feature provides inter-fabric routing to enable controlled
and limited access between devices on a QLogic fabric and devices on a fabric of
Brocade or Cisco switches.
Generally, to configure Transparent Router on a QLogic switch:
1. Change the port type of a selected port to TR_Port.
2. Map local (QLogic) and remote (e.g., Brocade/Cisco) fabric devices across
the TR_port.
3. Copy/paste the zoning commands automatically generated (by TR Mapping
Manager) into the remote fabric management application.
NOTE:
Enterprise Fabric Suite may not support all firmware versions. If the version
of Enterprise Fabric Suite is not supported, a warning status message
appears: FW/GUI mismatch. A switch with this status is still manageable, but
some functions may not be available. For firmware compatibility information,
see the Enterprise Fabric Suite Release Notes.
Table 2-1. Topology Display Switch and Status Icons
Switch Icon Description
Switch status icons
Normal operation (green)
Warning–operational with errors (yellow)
Critical–potential failure (red)
Unknown–communication status unknown, unreachable,
or unmanageable (blue)
Fabric management switch Ethernet icons
Ethernet connection normal (green)
Ethernet connection warning (yellow)
Ethernet connection critical (red)
Switch is not manageable with this version of Enterprise
Fabric Suite. Use the management application that was
shipped with this switch.
