Qlogic 5800V Series User Manual

6–Managing Ports
Viewing Port Information
6-2 59266-01 B
Figure 6-1. Port Information Data Window
The Port Information data window has several buttons from which you can choose
the type of information to display as shown in Table 6-1.
Table 6-1. Port Information Data Window Buttons
Button Description
Summary—basic port status information (Table 6-2)
Advanced—status of advanced features such as I/O StreamGuard
(message suppression) and Multiple Frame Sequence bundling
(Table 6-3)
Extended credit—extended credit and donor port information (Table 6-4)
Media—transceiver specifications and vendor information (Table 6-5)
DDM—Digital Diagnostics Monitoring (DDM); transceiver temperature,
voltage, current, and power values (Table 6-6)
