Qlogic 5800V Series

2–Managing Fabrics
Transparent Router
2-12 59266-01 B
To create a new TR mapping, click Add, or on the Edit menu, click Add to view
the Add TR Mapping dialog box. See ”Add TR Mapping Dialog Box” on page 2-13
for more information.
Select a TR mapping member in the TR Mapping List window to:
 Delete that TR mapping member
 View detailed information for that TR mapping member in the Selected TR
Mapping area
Figure 2-4. TR Mapping Manager Dialog Box
NOTE:
The Merge Auto Save option in the Config Zoning dialog box must be
selected before you can view the TR Mapping Manager dialog box. See
“Merge Auto Save” on page 4-10 for more information.
