5–Managing Switches
Configuring the Network
5-46 59266-01 B
Figure 5-22. Create Policy Dialog Box
Table 5-10 provides field definitions for the Create Policy dialog box.
Table 5-10. Create Policy Dialog Box Fields
Field Description
Name
User-defined, limited to 32 characters
Description
User-defined, limited to 127 characters
Mode IPsec mode options: transport, tunnel
Local Address Must be the switch's hostname, IPv4 or IPv6 address, or key-
word All for all the switch's addresses
Local Port QLogic switch IP ports to protect. Values between 1–65535, or
keyword All
