6–Managing Ports
Viewing Port Information
59266-01 B 6-5
Max Credits Avail-
able
Maximum number of credits granted to a port that can be used
when extending port credits
Credits to Donate Number of credits available to be donated by the selected port
Donor Group Donor group of the selected port
Valid Donor Groups Number of separate groups within which extended credits may
be donated and assigned
Table 6-5. Port Information Data Window—Media
Field Description
Media Type Transceiver fibre type, such as single mode, multi-mode, or cop-
per
Media Speed Maximum transceiver speed
Media Transceiver type
Media Transmitter Transceiver transmitter type, such as longwave, shortwave, or
electrical
Media Distance Maximum transceiver transmission distance
Media Vendor Company that manufactured the SFP
Media Vendor ID IEEE registered company identification number
Media Part Number Part number assigned to the SFP
Media Revision Transceiver hardware version
Table 6-4. Port Information Data Window—Extended Credits
Field Description
