Qlogic 5800V Series User Manual

5–Managing Switches
Viewing Switch Information
5-8 59266-01 B
Figure 5-6. Switch Data Window Buttons
The Switch data window boxes are described in Table 5-1.
Table 5-1. Switch Data Window Fields
Field Description
Summary Group
Switch Type Switch model
First Port Address Switch Fibre Channel address
World Wide Name Switch World Wide Name
Serial Number Number assigned to each chassis
Reason for Status Reason for the operational state
Vendor Switch manufacturer
MAC Address Media Access Control address
Negotiated Domain ID Domain ID currently being used by the fabric
Configured Domain ID Domain ID, defined by network administrator
Domain ID Lock Domain ID lock status. Prevents (True) or permits (False)
dynamic domain ID reassignment.
Number of Ports Number of physical ports on the switch
Operational State Switch operational state: Online, Offline, Diagnostic, Down
