5–Managing Switches
Viewing Switch Information
59266-01 B 5-9
Administrative State Current switch administrative state
Configured Admin
State
Administrative state that is stored in the switch configuration
Beacon Status Switch LEDs are blinking (On) or not blinking (Off).
Status Group
Operational State Switch operational state: Online, Offline, Diagnostic, Down
Administrative State Current switch administrative state
Configured Admin
State
Administrative state that is stored in the switch configuration
Beacon Status Beacon status. Switch LEDs are blinking (On) or not blinking
(Off).
Reason for Status Reason for the operational state
Temperature Internal switch temperature °C
Fan 1 Status Fan 1 operational status (dual power supply model only)
Fan 2 Status Fan 2 operational status (dual power supply model only)
Fan 3 Status Not applicable
Power Supply 1 Status Power supply 1 operational status
Power Supply 2 Status Power supply 2 operational status (dual power supply model
only)
Temperature Failure
Port Shutdown
Non-configurable (always enabled for this switch). All ports
are shut down when the switch temperature exceeds the Fail-
ure Temperature.
Warning Temperature Non-configurable temperature threshold, above which a warn-
ing condition alarm is generated
Failure Temperature Non-configurable temperature threshold, above which a fail-
ure condition alarm is generated
POST Status Current diagnostic state of the switch
POST Fault Code Code value for the last recorded diagnostic test result
recorded on the switch
Test Status Current diagnostic test status of switch
Table 5-1. Switch Data Window Fields (Continued)
Field Description
