Pre-Installation
CS210 Rev. B4 Feb 2015 15
– W10 from the fan control output module to the system connection box. This four-wire-cable is
used for data communication and power supply to the output module.
– W14 from the MI connection box to the system connection box and between MI connection boxes
when more than one shadow sensor is installed. This four-wire cable is used for data
communication and power supply to the pyrometer.
– W15 from the MR connection box to the system connection box. This six-wire cable is used for
data communication and power supply to the pyrometer.
– W16 MI sensing head cable.
– W17 MR sensing head cable.
– W18 Ethernet communication cable for scanner (preinstalled with system connection box)
– W20 Fibre optic cable from system connection box to the control room and to the second scanner
(if used). Fibre optic cable to be provided by customer.
– W22 Ethernet cable from fibre optic converter (control room) to the PC.
– W23 from the position indicator head to the junction box.
– W24 Power supply cable 100 to 240 VAC.
– W25 Fibre optic cable from the first scanner to the second scanner (if used). Fibre optic cable to be
provided by customer.
All copper cables must be shielded! The wires from W9, W10, W14, and W15 must be a
twisted pair! Local building codes should be observed when selecting cables!
