Pre-Installation
16 Rev. B4 Feb 2015 CS210
Cable
Distance
Cable features
Supplied from …
Example / Remarks
W1, W2,
W3
7.5 m (25 ft.)
preinstalled
Raytek
W8
350 m (380 yd)
3 x 0.25 mm²,
24 AWG, 3 conductor, shielded
Customer
(N)YLHCY-J 3 × 0.25 mm²
Manhattan/CDT, P/N M13233
W9
350 m (380 yd)
3 x 2 x 0.25 mm²,
24 AWG, 3x twisted pair, shielded
Customer
LifYCY 3 × 2 × 0.25 mm²
W10
350 m
(380 yd)
2 x 2 x 0.25 mm²,
24 AWG, 2 x twisted pair, shielded
Customer
W14
350 m (380 yd)
2 x 2 x 0.5 mm²,
20 AWG, 2 x twisted pair, shielded
Customer
max. 5 pyrometers
350 m (380 yd)
2 x 2 x 1.5 mm²,
16 AWG, 2 x twisted pair, shielded
Customer
max. 14 pyrometers
W15
350 m (380 yd)
3 x 2 x 1.5 mm²,
16 AWG, 3x twisted pair, shielded
Customer
W16
8 m (26 ft)
preinstalled
Raytek
W17
15 m (49 ft.)
preinstalled
Raytek
W18
7.5 m (25 ft.)
Raytek
W20
< 2 km (1.2 mi)
Fibre optic cable (outdoor),
2 fibres, multi-mode, 62.5/125 µm or
50/125 µm, equipped with SC
connectors
Customer
Standard cable designation:
A-DQ(ZN)B2Y…
W22
2 m (6.5 ft.)
Ethernet patch cable (CAT5, RJ-45)
Raytek
W23
5 m (15 ft.)
Raytek
W24
Power supply cable 100 to 240 VAC,
50 / 60 Hz, min. 3 x 1.5 mm² (16 AWG)
Customer
NYY
W25
< 2 km (1.2 mi)
Fibre optic cable (outdoor),
2 fibres, multi-mode, 62.5/125 µm or
50/125 µm, equipped with SC
connectors
Customer
Standard cable designation:
A-DQ(ZN)B2Y…
The cable length causes a certain voltage drop on the power cable. In case of using
multiple sensors (MI shadow pyrometers via W14), longer cable lengths, or less gauges
it must always be ensured, that the sensor will be supplied with the minimal voltage
power!
Linescanner: min. 18 VDC
MR burning zone pyrometer: min. 20 VDC
MI shadow pyrometer: min. 12 VDC
