Also, in the upper part of the screen, there’re some icons that permit you to:
• Display only the profile chart
• Display only the thermogram
• Display both (default option)
• 3D standard view for the thermogram
• 3D real time view for the thermogram (available as accessory), see section 11.5 3D Real Time
View, page 112)
Both in the chart and the thermogram, you can zoom into a specific area of the kiln. To
do so, click and drag from left to right, creating a square surrounding the area of
interest!
