9.4 CABLING IN THE RF CHASSIS
The interior of the 9508 RF chassis will have four cables installed. The cable part numbers and from-to
connections are shown in Table 9-6 and are shown pictorially in Figure 9-16.
Table 9-6. 9508 RF Chassis Cables
RFL cable part
number
From To Function
107806 (2 of 2) J1 of Power Amp
Power Supply
J1 of Power Amp 3-conductor cable which
provides dc power for Power
Amp
107854-17 J2 of Power Amp J4 of Motherboard Coax (high level output)
107854-27 J2 of Motherboard J4 or J5 of Power
Amp *
Coax (low level input)
107806 (1 of 2) J3 of Power Amp J9 of Motherboard 2-conductoir cable for
Amplifier Fail function
* If the coax is connected to J4, then J5 is unused. If the coax is connected to J5, then J4 is unused.
