RFL 9785 - Table 4-1. Controls and Indicators, RFL 9785 Front Panel

Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL 9785 RFL Electronics Inc.
March 24, 2008 4-3 (973) 334-3100
Table 4-1. Controls and indicators, RFL 9785 Front Panel
Item
Number
Name/Description Function
1 POWER ON indicator Lights green when system power is ON
2 STOP INPUT indicator Lights red when CARRIER STOP input is active
3 START INPUT indicator Lights red when CARRIER START input is active
4 BLOCK OUT indicator Lights red when a block condition has been detected
5 RX DETECT indicator Lights red when a received signal has been detected
6 RECEIVE LEVEL display Displays the power level of the received carrier signal in dB. The
range is –10 dB to +10 dB.
7 SOE RS-232 connector Allows a user to view the SOE log using a dumb terminal or a PC
with terminal emulation software. (See Section 16)
8 RESERVE INPUT indicator Lights red when RESERVE INPUT is active
9 REMOTE INITIATE indicator Lights red when REMOTE INITIATE is active
10 TX CARRIER ON indicator Lights red when TX CARRIER is active
11 TX FAIL indicator Lights red when the transmitter has failed.
