027 - High Rx HC
This parameter selects the received code that will cause the local terminal to respond with a
high-level hard carrier.
028 - HC Duration
This parameter sets the amount of time a hard carrier will be sent when the appropriate HARD
CARRIER REQUEST code is received. This can be set to either 30 or 60 seconds.
# PARAMETER SETTING # PARAMETER SETTING
999 System Label Station A
020 Mode Master 022 Hard Tx 1 03
023 Hard Tx 2
05
024 Hard Tx 3 00
025 Hard Tx 4
00
026 Low Rx HC 06
027 High Rx HC 04 028 HC Duration 30 sec
029 Hours Between 24 030 Response Time 20 sec
031 Hours To Next 03 032 Reset Log No
033 Chassis Type 85P
RFL 9785 RFL
E
lectronics Inc.
July 26, 2007
16-22 (973) 334-3100
Code Power Response
034 Test One 01 H 01
035 Test Two 02 L 02
036 Test Three 00 L 00
037 Test Four 00 L 00
038 Test Five 00 L 00
039 Test Six 00 L 00
040 Test Seven 00 L 00
041 Test Eight 00 L 00
Prin
ter Triggers
050 Receive Block Inactive
051 Lose Block Inactive
052 Test
Fail Inactive 053 Transmit Fail Inactive
055 Test OK Pulse No
9785CB-P>
Figure 16-16. Typical programmed parameter settings list – Master Mode
