9.6.3 BALANCE BOARD SETTINGS
The Balance Board has three jumpers J2, J3 and J4 that must be set for proper system operation. The
jumper settings select either 50W or 100W operation and must be set in accordance with Table 9-10.
The jumper locations are shown in Figure 9-8, and are accessible only when the Balance Board is
removed from the chassis.
Table 9-11. Setting Jumpers On Balance Board
Number Of J2 J3 J4
Amplifiers Jumper Settings Jumper Settings Jumper Settings
One (50W) 1-2 2-3 2-3
Two (100W) 2-3 1-2 1-2
