# PARAMETER SETTING # PARAMETER SETTING
999 System Label Station A
020 Mode Master
022 Hard Tx 1 03 023 Hard Tx 2 05
024 Hard Tx 3 00 025 Hard Tx 4 00
026 Low Rx HC 06 027 High Rx HC 04
028 HC Duration 30 sec 029 Hours Between 24
030 Response Time 20 sec 031 Hours To Next 03
032 Reset Log No 033 Chassis Type 85P
RFL 9785 RFL
E
lectronics Inc.
July 26, 2007
16-18 (973) 334-3100
Code Power Response
034 Test One 01 H 01
035 Test Two 02 L 02
036 Test Three 00 H 00
037 Test Four 00 L 00
038 Test Five 00 H 00
039 Test Six 00 L 00
040 Test Seven 00 H 00
041 Test Eight 00 L 00
Printer Triggers
050 Receive Block Inactive 051
Lose Block Inactive
052 Test Fail Active 053 Transmit Fail Inactive
055 Test Ok Pulse No
9785CB>
(Note: 00 indicates parameter not programmed)
Figure 16-12. Typical read settings menu
16.6.2.5 VIEWING CONFIGURATION AND SOFTWARE INFORMATION
The “F” command tells the Checkback Module to send a configuration and software version display to
your terminal. This display tells you how the Checkback Module is configured, and what software
version is being used.
Format: 9785CB>F [ENTER]
A typical configuration and software version display is shown in Figure 16-13.
9785 Checkback Configuration:
060 Version 1.4
9785CB>
Figure 16-13. Typical configuration and software version display
16.6.2.6 THE UPDATE MODE
The update mode places a display on your terminal that is constantly revised to show up-to-the-minute
information about Checkback Module operation. This mode is entered by using the “U” command.
Format: 9785CB>U [ENTER]
