10.2 SPECIFICATIONS
As of the date this manual was published, the following specifications apply to all RFL 9785 Output
Filter modules, except as indicated. Because all RFL products undergo constant refinement and
improvement, these specifications are subject to change without notice.
Frequency Range:
Assembly No. Frequency Range Notes
106530-1 30 kHz to 67.5 kHz
106530-2 64 kHz to157.5 kHz Without reflected power
m
easurement option
106530-3 154 kHz to 393.5 kHz
106530-4 390 kHz to 537.5 kHz
106530-5 114 kHz to 288.5 kHz
106530-11 30 kHz to 67.5 kHz
106530-12 64 kHz to157.5 kHz With reflected power
m
easurement option
106530-13 154 kHz to 393.5 kHz
106530-14 390 kHz to 537.5 kHz
106530-15 114 kHz to 288.5 kHz
Attenuation Notch:
Magnitude: Greater than 55 dB below passband level.
Approximate Frequency: See Table 10-2
Stopband:
Attenuation: Greater than 45 dB below passband level.
Approximate Frequency Range:
106530-1: 90 kHz to 2 mHz
106530-2: 192 kHz to 2 mHz
106530-3: 462 kHz to 2 mHz
106530-4: 1.17 mHz to 2 mHz
106530-5: 342 kHz to 2mHz
Passband: 0.75 dB deviation.
Signal Power: 10 watts maximum.
Impedance: 50 ohms.
RFL 9785 RFL Electronics Inc.
June 18, 2009 10-2 (973) 334-3100
