9.8 REAR PANEL WIRING FOR 9780/85 FOR 100W APPLICATIONS
Figure 9-24. Rear Panel Wiring Of Typical RFL 9785, 2W System, 100W Chassis
- +
TO
STATION
BATTERY
RX OUT
4W TX
OR 2W I/O
EXT AMP IN
TX IN
EXT AMP
OUT
EXT AMP
FAIL IN
C
NO
NO
C
NO
NC
EARTH GND
4W RX
INT
AMP
FAIL
EXT
AMP
FAIL
V+
V-
C
NO
NC
1
ALARM
RELAY
RX OUT
J
4W TX
OR 2W I/O
EXT AMP IN
TX IN
EXT AMP
OUT
EXT AMP
FAIL IN
C
NO
NO
C
NO
NC
CHASSIS GND
EARTH GND
4W RX
INT
AMP
FAIL
EXT
AMP
FAIL
V+
V-
C
NO
NC
WARNING:
THE FOLLOWING JUMPERS
MUST BE SET ON THE
EXTERNAL POWER/AMP I/O
J1-B
J2-B
J5-B
JP3-B
JP4-B
RF CHASSIS
9780/85 CHASSIS
THESE MODULES VARY DEPENDING
ON SYSTEM CONFIGURATION
O/FROM
LINE
COUPLING
EQUIPMENT
TX
T
SHOULD BE CONNECTED WITH
A SEPARATE WIRE TO THE
SUB-STATION GROUND BAR
