16.6.4.2 RUNNING TESTS
To run one or more Checkback Module tests, use the “T” command.
Format: 9785CB-T>T [ENTER]
When you enter the “T” command, the Checkback Module sends a list of all possible test routines to
your terminal. A typical test routine list is shown in Figure 16-19.
The values display shows the code number for each test routine, and a brief description of its meaning.
Full descriptions for each test routine are as follows:
060 - Key Carrier Low Power This routine energizes the reduced-power output.
061 - Key Carrier High Power This routine energizes the full-power output.
062 - Run Test Sequence This routine initiates the checkback test sequence.
063 - Send Code # This routine causes a specific code to be sent.
064 - Key Hard Carrier #1 This routine initiates Hard Carrier 1.
065 - Key Hard Carrier #2 This routine initiates Hard Carrier 2.
066 - Key Hard Carrier #3 This routine initiates Hard Carrier 3.
067 - Key Hard Carrier #4 This routine initiates Hard Carrier 4
H – Display test menu help
Q – Leave test menu
C – Change password (superuser aut
hori
zation required)
T – Redisplay tests
## - Run this test
9785CB-T>
Figure 16-18. Typical test menu
# DESCRIPTION
060 Key
Carrier Low Power
061 Key Carrier High Power
062 Run Test Sequence
063 Send Code #
064 Key Hard Carrier #1
065 Key Hard Carrier #2
066 Key Hard Carrier #3
067 Key Hard Carrier #4
9785CB-T>
Figure 16-19. Typical test routine list
RFL 9785 RFL E
lectronics Inc.
July 26, 2007
16-28 (973) 334-3100
