# PARAMETER SETTING # PARAMETER SETTING
999 System Label Station A
020 Mode Remote 022 Hard Tx 1 04
023 Hard Tx 2 06 024 Hard Tx 3 00
025 Hard Tx 4 00 026 Low Rx HC 05
027 High Rx HC 03 028 HC Duration 30 sec
032 Reset Log No 033 Chassis Type 85P
Incoming Response Power
034 Test One 01 01 H
035 Test Two 02 02 L
036 Test Three 00 00 L
037 Test Four 00 00 L
038 Test Five 00 00 L
039 Test Six 00 00 L
040 Test Seven 00 00 L
041 Test Eight 00 00 L
Printer Triggers
050 Receive Block Inactive 051 Lose Block Inactive
052 Test Fail Inactive 053 Transmit Fail Inactive
054 Rem Alarm Enable No
9785CB-P>
Figure 16-17. Typical programmed parameter settings list – Remote Mode
029 - Hours Between (Master only)
This parameter sets the amount of time between automatic checkback tests. This can be set
from one to 24 hours, in one-hour increments, and can only be set at the Master checkback
module. A value of 0 is used to disable automatic testing.
030 - Response Time (Master only)
This parameter sets the amount of time the Master checkback module will wait for a response
from a remote terminal before declaring a test failure. This can be set from 1 second to 255
seconds in one-second increments, and can only be set at the Master checkback module. Most
systems should operate properly with the response time set to 10 seconds.
031 - Hours To Next (Master only)
This parameter indicates the amount of time until the next automatic checkback test. Once it is
initially set, this parameter’s value is calculated, based on the setting of Parameter #29 (Hours
Between). Its range is from 0 (run test immediately) to the value of Hours Between.
RFL 9785 RFL Electronics Inc.
July 26, 2007 16-23 (973) 334-3100
