7.2 SPECIFICATIONS
As of the date this manual was published, the following specifications apply to all RFL 9785
Transmitter modules. Because all RFL products undergo constant refinement and improvement, these
specifications are subject to change without notice.
Output Frequency: 30 kHz to 535 kHz, adjustable in 10-Hz increments.
Frequency Stability: +10 Hz
Harmonic Content: Less than -55 dB.
Output Range (when used with RFL 9785 Power Amplifier Module):
10-Watt Output: 6.0 Vp-p
3-Watt Output: 3.4 Vp-p
1-Watt Output: 2.0 Vp-p
Voice Input: 1.6 Vp-p nominal; a 1000-Hz test tone at this level will produce 20 to 30 percent
modulation. Voice input level is adjusted on the optional RFL 9785 Voice Module (Section 15).
