RFL 9785 - Table 19-4. Controls and Indicators, Solid State Input;Output I;O Modules (Assembly No. 106635-1, -2, -3, and -4)

To Next Page

To Previous Page

Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and speciﬁcations without notice.

RFL

Sept

9785 RFL Electronics Inc.

ember 1, 2006

19-14 (973) 334-3100

Table 19-4. Controls and indicators, Solid State Input/Output I/O modules (Assembly No. 106635-1, -2, -3, and –4)

Component

Designator

Name/

Description

Function

J4 Jumper Selects 48V or 125V operation (not used for 250V operation)

J5 Jumper Selects 48V or 125V operation (not used for 250V operation)

TB1 Terminal block Provides connections to line coupling equipment

TB2 Terminal block Provides connections to line coupling equipment

P101 Checkback auxiliary chassis connector Provides connection to checkback auxiliary chassis
