Table 6-2. Switch Settings, DIP Switch SW1
Switch Section(s) Function Setting
SW1-1 Start Input
Polarity
ON (UP) Normally Energized
OFF(DOWN) Normally De-energized
SW1-2 Stop Input
Polarity
ON (UP) Normally Energized
OFF(DOWN) Normally De-energized
SW1-3 and SW1-4 Sets TX Power
Levels
SW1-3 SW1-4 Power Level
OFF(DOW
N) OFF(DOWN) 1W
OFF(DOWN) ON(UP) 3W
ON(UP) OFF(DOWN) 10W
ON(UP) ON(UP) 10W
SW1-5 TX Voice ON(UP) TX Voice Enabled
OFF(DOWN) TX Voice Disabled
SW1-6, SW1-7 & SW1-8 TX Fail See Table 6-3.
Table 6-3. Switch Settings, DIP Switch SW1-6, -7, -8
SW1-6
OFF(DOWN)
OFF(DOWN)
ON(UP)
ON(UP)
OFF(DOWN)
OFF(DOWN)
ON(UP)
ON(UP)
SW1-7
OFF(DOWN)
ON(UP)
OFF(DOWN)
ON(UP)
OFF(DOWN)
ON(UP)
OFF(DOWN)
ON(UP)
SW1-8
OFF(DOWN)
OFF(DOWN)
OFF(DOWN)
OFF(DOWN)
ON(UP)**
ON(UP)**
ON(UP)**
ON(UP)**
Normal Delay*
3mspu/2.5msdo
50mspu/2.5msdo
100mspu/2.5msdo
150mspu/2.5msdo
- - -
- - -
- - -
- - -
X4 Delay*
- - -
- - -
- - -
- - -
12mspu/2.5msdo
200mspu/2.5msdo
400mspu/2.5msdo
600mspu/2.5msdo
* mspu = millisecond pick-up
* msdo = millisecond drop-out delay
** ON for applications using 9505 amplifier
Table 6-4. Switch Settings, DIP Switch SW2-1, -2, -3, -4
Switch Section(s) Function Setting
SW2-1 Force Local RX Block ON(UP) Enabled
OFF(DOWN) Disabled
SW2-2 RX Voice Level ON(UP) High level voice
OFF(DOWN) Low level voice
SW2-3 SS Block Out #1 Polarity ON(UP) Normally energized
OFF(DOWN) Normally de-energized
SW2-4 SS Block Out #2 Polarity ON(UP) Normally energized
OFF(DOWN) Normally de-energized
SW2-5 N/A N/A
RFL 9785 RFL
E
lectronics Inc.
February 7, 2007 6-7 (973) 334-3100
