BIT SWITCHES
B404 5-18 SM
System Switch 0F
No FUNCTION COMMENTS
0
to
7
Country code for functional
settings (Hex)
00: France 11: USA
01: Germany 12: Asia
02: UK 13: Japan
03: Italy 14: Hong Kong
04: Austria 15: South Africa
05: Belgium 16: Australia
06: Denmark 17: New Zealand
07: Finland 18: Singapore
08: Ireland 19: Malaysia
09: Norway 1A: China
0A: Sweden 1B: Taiwan
0B: Switz. 1C: Korea
0C: Portugal 20: Turkey
0D: Holland 21: Greece
0E: Spain 22: Hungary
0F: Israel 23: Czech
10: Not used 24: Poland
This country code determines the factory settings of
bit switches and RAM addresses. However, it has
no effect on the NCU parameter settings and
communication parameter RAM addresses.
Cross reference
NCU country code: Function 08, parameter C.C.
System Switch 10
No FUNCTION COMMENTS
0
to
7
Threshold memory level for
parallel memory transmission
Threshold = N x 128 kbytes + 256 kbytes
N can be between 00 - FF(H)
Default setting: 02(H) = 512 kbytes
System Switch 11
No FUNCTION COMMENTS
0 TTI printing position
0: Superimposed on the page
data
1: Printed before the data
leading edge
Change this bit to 1 if the TTI overprints information
that the customer considers to be important (G3
transmissions).
1-7 Not used Do not change the settings.
System Switch 12
No FUNCTION COMMENTS
0
to
7
TTI printing position in the main
scan direction
TTI/CIL: 08 to 64 (BCD) mm
Input even numbers only.
This setting determines the print start position for
the TTI and CIL from the left edge of the paper. If
the TTI is moved too far to the right, it may overwrite
the file number which is on the top right of the page.
This machine does not have a Group 4 option.
