Fax Unit B404
BIT SWITCHES
SM 5-19 B404
System Switch 13 - Not used (do not change the settings)
System Switch 14 - Not used (do not change the settings)
System Switch 15
No FUNCTION COMMENTS
0 Not used Do not change the settings.
1 Going into the Sleep mode
automatically
0: Enabled
1: Disabled
1: The machine will restart from the Energy Saver
mode quickly, because the +5V power supply is
active even in the Energy Saver mode.
2 Protocol dump data backup
0: Disabled
1: Enabled
1: The machine backs up the protocol dump data for
approximately one hour when the main switch is
turned off, in the same way as image data.
3-7 Not used Do not change the settings.
System Switch 16 - Not used (do not change the settings)
System Switch 17
No FUNCTION COMMENTS
1-5 Not used Do not change the settings.
6 Memory Lock function
0: Disabled
1: Enabled
Change this bit to “1” when the customer requests.
7 Not used Do not change the setting.
System Switch 18 - Not used (do not change the settings)
System Switch 19
No FUNCTION COMMENTS
0-6 Not used Do not change the setting.
7 Special Original mode
0: Disabled
1: Enabled
1: If the customer frequently wishes to transmit a form
or letterhead which has a colored or printed
background, change this bit to “1”. “Special Original”
can be selected in addition to the “Text” and “Photo”
modes.
When this mode is selected, the “Text” and “Photo”
LEDs are both lit.
Cross reference
!
Type of special original mode – Scanner switch 00
bit 0.
