BIT SWITCHES
B404 5-20 SM
System Switch 1A - Not used (do not change the settings)
System Switch 1B - Not used (do not change the settings)
System Switch 1C - Not used (do not change the settings)
System Switch 1D
No FUNCTION COMMENTS
0 RTI/CSI display during
communication
0: Enabled
1: Disabled
If enabled, the machine displays the RTI/CSI on the
LCD panel during communication.
1-7 Not used Do not change the settings.
System Switch 1E
No FUNCTION COMMENTS
0 Communication after the
Journal data storage area has
become full
0: Possible
1: Impossible
This setting is effective only when Automatic Journal
printout is enabled.
0: If the buffer memory of the communication
records for the Journal is full, fax communications
are still possible. But the machine will overwrite the
oldest communication records.
1: If the buffer memory of the communication
records for the Journal has become full, fax
communications will become impossible, to prevent
overwriting the communication records before the
machine prints them out.
Cross Reference
!
Automatic Journal output - User switch 03 bit 7
!
Number of communication records for the
Journal:
100 records
1
Action when the SAF memory
has become full during
scanning
0: The current page is erased.
1: The entire file is erased.
0: If the SAF memory becomes full during scanning,
the successfully scanned pages are transmitted.
1: If the SAF memory becomes full during scanning,
the file is erased and no pages are transmitted.
Not applicable to parallel memory transmission
2
RTI/CSI display priority
0: RTI 1: CSI
This bit determines which identifier, RTI or CSI, is
displayed on the LCD while the machine is
communicating in G3 non-standard mode.
3 Not used Do not change the setting.
4 Action when authorized
reception is enabled but
authorized RTIs/CSIs are not
yet programmed:
0: All fax reception is disabled
1: Faxes can be received if the
sender has an RTI or CSI
This determines how the machine behaves if
authorized reception is enabled but the user has
stored no acceptable sender RTIs or CSIs.
0: The machine will not be able to receive any fax
messages.
1: Messages from senders that include an RTI or
CSI will be received.
