BIT SWITCHES
B404 5-26 SM
Scanner Switch 0F
No FUNCTION COMMENTS
0 Image rotation before
transmission (A4/LT LEF)
0: Disabled
1: Enabled
This bit determines whether the machine rotates the
scanned image by 90 degrees before transmission.
If this bit is set at 1, A4 (LT) LEF images (297 mm
width in the protocol) will be transmitted as A4 (LT)
SEF images (216 mm width in the protocol).
1 Not used Do not change the setting.
2 Image rotation before
transmission (A5/HLT SEF)
0: Disabled
1: Enabled
This bit determines whether the machine rotates the
scanned image by 90 degrees before transmission.
If this bit is set at “1”, A5 (HLT) SEF images will be
transmitted as A4 (LT) width images (216 mm width
in the protocol).
3-7 Not used Do not change the settings.
