Ricoh D117 User Manual

Controller Options
SM 2-101 D117/D118
Installation
2.14.9 SD CARD FOR NETWARE PRINTING TYPE J
 Unplug the main machine power cord before you do the following procedure.
1. Remove the SD-card slot cover [A] from the SD card slots (
x 1).
2. Insert the SD card (Netware Printing) in SD slot 1 (upper) with its label face [A] to the rear of
the machine..
3. Attach the SD-card slot cover, and then turn on the machine (
x 1).
4. Make sure that the machine can recognize the option (see "Check All Connections" at the end
of this section).

Ricoh D117 Specifications

General

Functions	Print, Copy, Scan, Fax
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Maximum Paper Size	A4
Product Type	All-in-One Printer
Print Technology	Laser
Scan Type	Flatbed, ADF
Paper Handling Input	250-sheet input tray
Paper Capacity	250 sheets
Connectivity	USB, Ethernet
Operating System Compatibility	Windows, Mac
