Ricoh D117 - Middle:edgeenvcorrection; Middle:envcorrectiontable; Thin:bias; Thin:bias:bw

Main SP Tables-2
SM Appendix 3-123 D117/D118
Appendix:
SP Mode
Tables
2459 [Middle:EnvCorrectionTable]
013
Separation
DC:Standard:1side
*ENG
[1 to 100 / 30 / 1/step]
014
Separation
DC:Standard:2side
*ENG
015 Separation DC:Low:1side *ENG
016 Separation DC:Low:2side *ENG
2459 [Middle:EdgeEnvCorrection]
017
Separation
DC:Standard:1side
*ENG
[1 to 100 / 50 / 1/step]
018
Separation
DC:Standard:2side
*ENG
019 Separation DC:Low:1side *ENG
020 Separation DC:Low:2side *ENG
2461
[Thin:Bias]
Adjusts the DC voltage of the discharge plate for thin paper.
001
Separation
DC:standard:1side
*ENG [0 to 4000 / 2000 / 10-V/step]
003 Separation DC:low:1side *ENG [0 to 4000 / 2000 / 10-V/step]
2463
[Thin:Bias:BW]
Adjusts the current for the paper transfer roller for thin paper in black-and-white
mode.
001 PaperTransfer:Standard:1Sid *ENG [0 to 200 / 13 / 1-uA/step]
003 Paper Transfer:Low:1side *ENG [0 to 200 / 11 / 1-uA/step]
